€17,55 €17,55 inc. BTW
Driver_LC_35W_700_800_1050mA_flexC_SR_ADV_28652
Product description
_ Independent fixed output LED driver
_ For luminaires of protection class I and protection class II
_ For luminaires with M and MM as per EN 60598, VDE 0710 and
VDE 0711
_ Temperature protection as per EN 61347-2-13 C5e
_ Adjustable output current between 700, 800 and 1,050 mA
_ Max. output power 35 W
_ Up to 87.5 % efficiency
_ Nominal lifetime up to 50,000 h
_ 5 years guarantee (conditions at
https://www.tridonic.com/en/int/services/manufacturerguarantee-conditions)
Housing properties
_ Casing: polycarbonate, white
_ Type of protection IP20
Interfaces
_ Input terminals: 0° screw terminals
_ Output terminals: 45° push terminals
Functions
_ Overload protection
_ Short-circuit protection
_ No-load protection
_ Overtemperature protection
_ Burst protection voltage 1 kV
_ Burst protection voltage 1 kV (L to N)
_ Surge protection voltage 2 kV (L/N to earth)
Typical applications
_ For spot light and downlight in retail and hospitality applications
_ For panel light and area light in office and education application
Op voorraad
